15000 Bottles Per Hour Pure Water / Tea / Juice Filling Machine Fully Automatic
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| High Light: | plastic bottle unscrambler,bottle unscrambler machines |
||
|---|---|---|---|
15000 Bottles Per Hour Pure Water / Tea / Juice Filling Machine Fully Automatic
1. Low loss, low noise
2. High quality, high efficiency
3. Safe use
4. Fully automatic
Description:
Moderate temperature filling technology adopts nor-mal PET bottle and fills tea drinks and drinks juice at 68℃. Products can reach the requirement of shelf life without any preservatives. The capacity ranges from 5,000BPH to 36,000BPH.
Specifications:
ZXGF PET bottle 4/5 in 1 cooling chain filling machine makes up sterilize, washing, filling, capping and CIP rinsing, which bases of recommending, digesting and receiving from foreign advanced technology. According to hot filling working process of China’s tea and juice beverage, we develop and design the advanced PET bottle hot filling machines in domestic.
Technique Parameters:
|
model |
ZXGF40-40-40-10 |
|
|
working position |
washing bottle40 bottle washing 40 filling 40 capping10 |
|
|
capacity |
15000BPH (500ml/B) |
|
|
Suitable bottle model |
Bottle dia. |
50 ~115mm |
|
Bottle height |
190 ~320mm |
|
|
Air source pressure |
0.7MPa |
|
|
Air consumption |
0.8 m3/min |
|
|
Bottle washing water consumption |
2.4t/h |
|
|
Working pressure (AC) |
380V |
|
|
Control voltage (DC) |
24V |
|
|
Main motor power |
5.5KW |
|
|
Dimension |
L7100-W3000-H2200 |
|
